Name: Inspection Procedures for Industrial Weighing Systems
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Procédures d'inspection pour les systèmes de pesage industriel
Availability: InStock

Aperçu Produits Trieuse pondérale automatique

Inspection Procedures for Industrial Weighing Systems

Détails sur le produit:

Lieu d'origine:	CHINE
Numéro de modèle:	Procédures d'inspection pour les systèmes de pesage industriel

Conditions de paiement et expédition:

Quantité de commande min:	1 set
Prix:	Négociable
Détails d'emballage:	Caron
Délai de livraison:	10-30 jours
Capacité d'approvisionnement:	2000 set par mois

Contact

Description de produit détaillée

Product:	Inspection Procedures for Industrial Weighing Systems	Weighing Range:	Min: 0.1 kg – Max: 50,000 kg (varies by model)
Tolerance (Error Limit):	±0.1% of reading (for Class III) or ±1 division (whichever is stricter)	Frequency:	Every 6 months (or after 500 hours of operation)
Calibration Weights:	Class F1/M1 (OIML R111) with valid certification	Temperature Range:	-10°C to +40°C (operational), -20°C to +60°C (storage)
Humidity Tolerance:	10% to 90% RH (non-condensing)	Load Cell Type:	Strain gauge (standard), Capacitive (high precision)
Overload Protection:	150% of max capacity (safety limit)	Power Supply:	110–240V AC, 50/60Hz or 24V DC (±5%)
EMC/EMI Resistance:	Complies with EN 61326-1 (industrial EMC standards)	Repeatability:	±0.05% of applied load (test with 10 repeated measurements)
Linearity Error:	±0.2% of full scale	Material Safety:	Stainless steel (Grade 316) for corrosive environments
Legal-for-Trade:	NTEP, MID (EU), OIML certification (if used in commerce)	Calibration Certificate:	Must include date, technician, uncertainty, traceability
User Manual:	Must cover installation, operation, maintenance, troubleshooting
Mettre en évidence:	industrial weighing system inspection , load cell inspection procedures , Mettler Toledo weighing system maintenance

Inspection Procedures for Industrial Weighing Systems

Comprehensive inspection procedures for industrial weighing systems to ensure accuracy, safety, and compliance with industry standards.

Technical Specifications

Attribute	Value
Weighing Range	Min: 0.1 kg – Max: 50,000 kg (varies by model)
Tolerance (Error Limit)	±0.1% of reading (for Class III) or ±1 division (whichever is stricter)
Frequency	Every 6 months (or after 500 hours of operation)
Calibration Weights	Class F1/M1 (OIML R111) with valid certification
Temperature Range	-10°C to +40°C (operational), -20°C to +60°C (storage)
Humidity Tolerance	10% to 90% RH (non-condensing)
Load Cell Type	Strain gauge (standard), Capacitive (high precision)
Overload Protection	150% of max capacity (safety limit)
Power Supply	110–240V AC, 50/60Hz or 24V DC (±5%)
EMC/EMI Resistance	Complies with EN 61326-1 (industrial EMC standards)

Inspection Process Overview

Industrial weighing system inspections involve evaluating mechanical integrity, electronic performance, and overall functionality to maintain measurement reliability and compliance.

Pre-Inspection Checks

Visual Inspection: Examine for damage, wear, or corrosion on platform and support structure
Cable and Connection Check: Verify all connections are secure and undamaged
Foundation and Environment: Assess for stability and environmental factors affecting performance

Calibration and Verification

Zero Balance Check: Verify stable zero reading with no load
Span Calibration: Test accuracy across weighing range using certified test weights
Repeatability Test: Confirm consistent readings with repeated measurements

Functional and Operational Tests

Load Cell Performance: Verify proper function and balanced outputs
Indicator and Software Check: Test display functionality and data transmission
Safety and Overload Test: Confirm proper activation of overload protection

Produit Tag:

Personne à contacter: Mrs. Shirley

Téléphone: +86-15851932889

Télécopieur: 86-519-68781609
